|Operating Weight (Ripper Not Included):||37.2t||L×W×H (Ripper Not Included):||6880×4130×3725 Mm|
|Rated Power:||235/2000kW/rpm||Grade Ability:||30°|
shantui construction machinery,
heavy equipment bulldozer
Heavy Earth Moving Machinery Shantui Bulldozer SD32 37 Tons Operating Weight
|L×W×H (Ripper not included)||6880×4130×3725 mm||Ripping depth of ripper||Single ripper 1250mm|
|Operating weight (Ripper not included)||37.2t||Three-shank ripper 842 mm|
|Rated power||235/2000kW/rpm||Lifting height of ripper||Single ripper 955Three-shank ripper 883|
|Grade ability||30°||Number of carriers (each side)||2|
|Blade type||Straight tilt bladeSemi-U bladeAngle blade||Number of track rollers (each side)||7|
|Blade width||Straight tilt blade 4130×1590 mm||Number of track shoes (each side)||41|
|Width of track shoe||560 mm|
|Semi-U blade 4030×1720mm|
|Track gauge||2140 mm|
|Angle blade 5000×1140mm|
|Ground length and ground pressure||3150-0.105 mm/MPa|
|Dozing capacity||Straight tilt blade 10 m3||Pitch||228.6mm|
|Semi-U blade 11.9 m3|
|Angle blade 6 m3||0–6.6km/h|
|Ma× drop below ground of blade||560 mm||Reverse speed||0–4.4km/h|
|Lift height of blade||1560 mm||0–7.8km/h|
|Ripper type||Single ripper Three-shank ripper||0–13.5km/h|
In response to the demands of severe working conditions in earthwork projects, SD32 crawler bulldozer is a high power bulldozer under standardized mass production with the application of domestic leading production processes and technologies.
1. Chongfa NTAA855-C360S10 engine is equipped with exhaust gas turbocharger, featuring strong power and high efficiency and energy-saving, and can work normally even in the highlands as high as 3,600m. Depending on the customers’ demands, the option Cummins and Weichai engines are available.
2. The high reliability power shift transmission, the stable hydraulic torque converter, and two-stage spur gear final drive feature high power transmission capacity and efficiency and high productivity.
3. The independent engine water tank, the chassis oil cooler, and the water-air inter cooler integrated in the Chongfa engine provide prominent cooling performance and simple maintenance operations to guarantee the continuous working of the machine.
