938 Wheeled Frond End Loader With 40km/H Max.Speed Of Yj315 Transmission Grab Fork As Optional

China 938 Wheeled Frond End Loader With 40km/H Max.Speed Of Yj315 Transmission Grab Fork As Optional supplier

Large Image :  938 Wheeled Frond End Loader With 40km/H Max.Speed Of Yj315 Transmission Grab Fork As Optional

Product Details:

Place of Origin: China
Brand Name: SINOMTP
Certification: ISO/CCC/BV
Model Number: LG938

Payment & Shipping Terms:

Minimum Order Quantity: 1 unit
Price: negotiation
Packaging Details: NUDE
Delivery Time: 35 days after payment
Supply Ability: 100 units per month
Detailed Product Description
Model: SINOMTP LG938 Engine: Weichai
Parking Brake: Manual Disk Brake Type Specification: 17.5-25
Front Tyre Pressure: 0.4Mpa Color: Yellow, White

938 frond end wheel loader with 40km/h max.speed of YJ315 transmission grab fork as optional



SPECIFICATION:



Performance 1 rated loading 3000kg
  2 overall weight 9800kg
  3 rated bucket capacity 1.8m3
  4 maximum tractive force 97KN
  5 maximum breakout force 127KN
  6 maximum grade ability 30℃
  7 maximum dump height 3100
  8 maximum dump reach 1006mm
  9 overall dimension (L×W×H) 6890×2430×3070mm
  10 minimum turning radius 5097mm
Engine 11 model Deutz WP6G125E22
  12 type lnline water cooled, four stroke
  13 No. of cylinder-bore/stroke 6—108×125mm
  14 rated power 92kw
  15 maximum torque 500N.m
  16 min fuel-consume ratio ≤210g/kw.h
Transmission system 17 torque converter YJ315
  18 gearbox mode Power shift normally engaged straight gear
  19 gear shift 4forward shift 2 reverse shift
  20 maximum speed 40km/h
Drive axles 21 main reducing mode Bevel gear grade lreduction
  22 decelerating mode Bevel gear grade lreduction
  23 wheel base (mm) 2660mm
  24 wheel tread 1800mm
  25 ground clearance 400mm
Hydraulic system 26 system working pressure 16.5MPa
  27 boom lifting time 4.83s
  28 total time 9.15s±0.5s
  29 fuel tank capacity 156L
  30 function of leveling automatically yes



938 Wheeled Frond End Loader With 40km/H Max.Speed Of Yj315 Transmission Grab Fork As Optional938 Wheeled Frond End Loader With 40km/H Max.Speed Of Yj315 Transmission Grab Fork As Optional
