3000kg Loading Capacity Wheel Heavy Equipment Loader With 127kn Breakout Force And 3100mm Dump Height

China 3000kg Loading Capacity Wheel Heavy Equipment Loader With 127kn Breakout Force And 3100mm Dump Height supplier

Large Image :  3000kg Loading Capacity Wheel Heavy Equipment Loader With 127kn Breakout Force And 3100mm Dump Height

Product Details:

Place of Origin: China
Brand Name: SINOMTP
Certification: ISO/CCC/BV
Model Number: LG938

Payment & Shipping Terms:

Minimum Order Quantity: 1 unit
Price: negotiation
Packaging Details: NUDE
Delivery Time: 35 days after payment
Supply Ability: 100 units per month
Detailed Product Description
Model: SINOMTP LG938 Engine: Weichai Engine
Dimension: 6890×2430×3070mm Dump Reach: 1006mm
Front Tyre Pressure: 0.4Mpa Color: Yellow, White

3000kg loading capacity wheel loader from SINOMTP with 127kn breakout force and 3100mm dump height



SPECIFICATION:

Performance 1 rated loading 3000kg
2 overall weight 9800kg
3 rated bucket capacity 1.8m3
4 maximum tractive force 97KN
5 maximum breakout force 127KN
6 maximum grade ability 30℃
7 maximum dump height 3100
8 maximum dump reach 1006mm
9 overall dimension (L×W×H) 6890×2430×3070mm
10 minimum turning radius 5097mm
Engine 11 model Deutz WP6G125E22
12 type lnline water cooled, four stroke
13 No. of cylinder-bore/stroke 6—108×125mm
14 rated power 92kw
15 maximum torque 500N.m
16 min fuel-consume ratio ≤210g/kw.h
Transmission system 17 torque converter YJ315
18 gearbox mode Power shift normally engaged straight gear
19 gear shift 4forward shift 2 reverse shift
20 maximum speed 40km/h
Drive axles 21 main reducing mode Bevel gear grade lreduction
22 decelerating mode Bevel gear grade lreduction
23 wheel base (mm) 2660mm
24 wheel tread 1800mm
25 ground clearance 400mm
Hydraulic system 26 system working pressure 16.5MPa
27 boom lifting time 4.83s
28 total time 9.15s±0.5s
29 fuel tank capacity 156L
30 function of leveling automatically yes
Brake system 31 service brake air assist disc brake on 4 wheels
32 parking brake Manual disk brake
Tyre 33 type specification 17.5-25
34 front tyre pressure 0.4Mpa
35 rear tyre pressure 0.35Mpa



3000kg Loading Capacity Wheel Heavy Equipment Loader With 127kn Breakout Force And 3100mm Dump Height3000kg Loading Capacity Wheel Heavy Equipment Loader With 127kn Breakout Force And 3100mm Dump Height
