Product Details:
Payment & Shipping Terms:
|
| Model: | SDLG | Engine: | YC4D80-T20 |
|---|---|---|---|
| Transmission: | Shantui BD05N1+Forward II / Reverse II | Rated Load (kg): | 1800 |
| High Light: | Wheel Loader equipment,heavy equipment loader |
||
SDLG wheel loader LG918 Yuchai engine with 1 , 8 tons loading capacity
Specification:
| Item | LG918 | Engine | YC4D80-T20; Diesel; 2400 r/min; 4 cylinders; Air Intake; GB 20891 Stage II; 265 N.m for Max torque |
| Transmission | Shantui BD05N1+Forward II / Reverse II | Bucket Capacity ( m3) | 1 |
| Axle | SDLG | Rated Load (kg) | 1800 |
| Hydraulic System | Pilot Control | Max Dumping Height (mm) | 2510 |
| Working Arm | Standard | Cycle Time (s) | ≤9.1 |
| Control Valve | 2 Valve | Min Steering Radius (mm) | 4546 |
| Brake System | Dual Brake Petal | Max Breakout Force (KN) | ≥58 |
| Cab | Standard | Dimension (L*W*H) (mm) | 5798*2140*2920 |
| Cooling/Heating System | Air Conditioner | Operating Weight (kg) | 6200 |
| Quick Coupler | No | Attachment | Optional |
Description:
LG918 loader is a high-end product mainly for loading and unloading loose materials. The entire machine is compact flexible in operation, of high working efficiency, more suitable for operation in narrow and small field and is widely used in places such as farms, timber yard and municipal construction.
Advantages:
1. It is equipped with engine meeting the requirements of China II emission standard with strong power, low noise and reliable performance.
2. Single-stage three-element hydraulic torque converter and axis-fixed transmission case are used, with high reliability and are convenient for maintenance; SDLG reinforced drive axle is configured, with large bearing capacity, long service life and high reliability.
3. Load-sensing full hydraulic steering system is used with light and quick steering and reliable energy saving properties; Pilot-control working device hydraulic system is used, with high operating efficiency and is light and easy to operate.
4. It adopts front and rear reinforced frames that have passed 200.000 times of fatigue enhancement tests, with strong bearing capacity, reasonable entire-machine load distribution and good stability.
