Product Details:
Payment & Shipping Terms:
|
| Name: | High Lifting Arm GP Bucket | Code: | 1690200031 |
|---|---|---|---|
| Bucket Capacity: | 1.6 M3 | Rated Load: | 2.7 T |
| High Light: | construction equipment parts,heavy equipment parts |
||
high lifting arm GP bucket of SDLG wheel loader of 1.8m3 capacity
Specification:
| Name |
high lifting arm GP bucket |
Dumping distance (mm) |
1020 |
| Code | 1690200031 |
Min.steering radius (attachment)(mm) |
6070 |
| Bucket capacity (m3) | 1.6 | Overall dimension of WL (LxWxH) (mm) | 7266x2510x3087 |
| Attachment weight (kg) | 735 |
Min.steering radius (tyre) (mm) |
5349 |
|
Attachment dimension (LxWxH) (mm) |
2510x1200x1112 |
Max.breakour force (kN) |
≥92 |
| Rated load (t) | 2.7 | Operating weight (kg) | 10700 |
| Max.dumping heght (mm) | 3278 | ||
Application:
High lifting arm general purpose bucket, mainly used in loading bulk materials, like ore, soil, stone, lime, can be equipped to these models: LG936L.
