Mining 7 Ton SDLG Construction Equipment Dual Brake Pedall With 4.2m3 GP bucket

China Mining 7 Ton SDLG Construction Equipment Dual Brake Pedall With 4.2m3 GP bucket supplier
Mining 7 Ton SDLG Construction Equipment Dual Brake Pedall With 4.2m3 GP bucket supplier Mining 7 Ton SDLG Construction Equipment Dual Brake Pedall With 4.2m3 GP bucket supplier

Large Image :  Mining 7 Ton SDLG Construction Equipment Dual Brake Pedall With 4.2m3 GP bucket

Product Details:

Place of Origin: China
Brand Name: SDLG
Certification: ISO/CCC
Model Number: LG978

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: Negotiation
Packaging Details: Nude packing
Delivery Time: 30 work days
Payment Terms: T/T, L/C
Supply Ability: 100 units/month
Contact Now
Detailed Product Description
Model: LG978 Engine: WD12G310E221
Bucket Capacity ( M3): 4.2 Rated Load (kg): 7000
Brake System: Pilot Control Single Levers Operating Weight: 23500
High Light:

heavy equipment loader

,

loader construction equipment

Mining 7 Ton SDLG Construction Equipment Dual Brake Pedall With 4.2m3 GP bucket





Specification:





Item LG978 Engine Weichai WD12G310E221
Transmission SDLG Fixed shaft electro-hydraulic shift+Forward IV/Reverse VI Bucket Capacity ( m3) 4.2
Axle SDLG A503 Rated Load (kg) 7000
Hydraulic System Pilot Control single levers Max Dumping Height (mm) 3250
Working Arm Standard Cycle Time (s) ≤11.7
Control Valve 2 Valve Min Steering Radius (mm) 7565
Brake System Dual Brake Pedall Max Breakout Force (KN) ≥216
Cab FOPS&ROPS Dimension (L*W*H) (mm) 8832*3200*3665
Cooling/Heating System Air Conditioner Operating Weight (kg) 23500
Quick Coupler No Attachment GP bucket



Description:

LG978 is a luxury and comfortable loader for loading and unloading heavy-load materials with large breakout force, comfortable operation condition, high operating efficiency.



Advantages:

  1. Low-speed and large-torque engine meeting the requirement of China II emission standard is provided, with strong power, low noise, reliable performance, horizontally-mounted air filter and is convenient for repair and maintenance.
  2. SDLG specially-imported HT220 axis-fixed electric-liquid shift transmission case is used, with four point gear positions and four rear gear positions and is flexible and high efficient.
  3. SDLG reinforced drive axle is configured. Full hydraulic travel braking system is used, with stable and reliable braking property and is convenient for repair and maintenance.
  4. It is equipped with boxed independent radiating and cooling system of SDLG patent and hydraulic motor-driven fan.



Application:

It is widely used in building site, mining, wharf for loading and unloading.

Mining 7 Ton SDLG Construction Equipment Dual Brake Pedall With 4.2m3 GP bucketMining 7 Ton SDLG Construction Equipment Dual Brake Pedall With 4.2m3 GP bucket
