LG953N wheel loader with weichai WD10G220E23 polit control with 5 tons loading capacity

Certification
Good quality Hydraulic Crawler Excavator for sales
Good quality Hydraulic Crawler Excavator for sales
Thanks for all your cooperation, the more orders, the better service.....

—— Johnny Benson

Yesterday, we cooperated and trusted each, tomorrow, we share the same breath for win-win. My friend, thank you.

—— Charles Soludo

Since We choose your factory and trucks, we are in good way!

—— HADJADJ EL-HASSEN

Nous sommes une entreprise en Togo, nous avons bien collaboré avec SINOTRUK KOGEL depuis 7 ans. Grace à son support, nous possèdons un très bon marché

—— Dinga

I'm Online Chat Now

LG953N wheel loader with weichai WD10G220E23 polit control with 5 tons loading capacity

China LG953N wheel loader with weichai WD10G220E23 polit control with 5 tons loading capacity supplier
LG953N wheel loader with weichai WD10G220E23 polit control with 5 tons loading capacity supplier LG953N wheel loader with weichai WD10G220E23 polit control with 5 tons loading capacity supplier LG953N wheel loader with weichai WD10G220E23 polit control with 5 tons loading capacity supplier

Large Image :  LG953N wheel loader with weichai WD10G220E23 polit control with 5 tons loading capacity

Product Details:

Place of Origin: China
Brand Name: SINOMTP
Certification: ISO/CCC
Model Number: LG953N

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: Negotiation
Packaging Details: Nude
Delivery Time: 30 work days
Supply Ability: 100 units/month
Contact Now
Detailed Product Description
Model: SDLG Engine: Weichai WD10G220E23
Rated Load (kg): 5000 Hydraulic System: Pilot Control
Operating Weight (kg: 16600 Quick Coupler: Optional
High Light:

heavy equipment loader

,

loader construction equipment

LG953N wheel loader with weichai WD10G220E23 polit control with 5 tons loading capacity



Specification:



Item LG953N Engine WD10G220E23
Transmission LG A307A Bucket Capacity ( m3) 2.8
Axle SDLG+A512 Rated Load (kg) 5000
Hydraulic System Pilot Control Max Dumping Height (mm) 3278
Working Arm Standard Cycle Time (s) ≤10.3
Control Valve 3 Valve Min Steering Radius (mm) 6070
Brake System Dual Brake Petal Max Breakout Force (KN) ≥185
Cab Standard Dimension (L*W*H) (mm) 7794*3024*3423
Cooling/Heating System Air Conditioner Operating Weight (kg) 16600
Quick Coupler NO Attachment Optional



Description:



LG953N, a long-wheelbase loader for loading bulk materials and hard materials, features large breakout force and tipping load enjoyed by long-wheelbase loader as well as the flexibility and small turning angle enjoyed by short-wheelbase loader, and is widely applied in areas like sand plants, ports, construction sites, mines etc.



Advantages:



1. New steel structure cab is adopted, which has wide vision, larger operation space, fully-covered cab internal trimmings, good sealing performance and comfortable driving environment; The air conditioner and ROPS&FOPS cab can be installed optionally, which ensures good comfort.



2. Load-sensing full hydraulic steering system and pilot-control working device hydraulic system are used, with high operating efficiency and are light and easy to operate; Hydraulic pipeline is double sealed, with high reliability.



3. It is equipped with the Weichai DEUTZ turbocharged engine meeting the requirements of China II emission standard, with strong power and high reliability; Dachai DEUTZ Engine is alternative.





4. Bucket is made of protruding type cutting board. The bottom antifriction plate is thickened, with little cutting resistance, high coefficient of fullness and high reliability.



LG953N wheel loader with weichai WD10G220E23 polit control with 5 tons loading capacity
