Product Details:
Payment & Shipping Terms:
|
| Model: | XG520 | Rated Load: | 2000 Kg |
|---|---|---|---|
| Lift Height: | 3000 Mm | Power Type: | Diesel |
| Fork (L×W×H): | 1070x122x40 | Deadweight: | 3440kg |
| High Light: | forklift pallet truck,forklift lift truck |
||
2000 Kg Loading Industrial Forklift Truck 1650L Wheel Base With High Air Inflow Silencing
Specifications:
| Product | Forklift truck | Min. Turning radius (R)(mm) | 2200 |
| Model | XG520 | Min. ground clearance (H3)(mm) | 110 |
| Power type | Diesel | Max. Running speed(km/h) | 20 |
| Rated load(kg) | 2000 | Lifting speed (full load)(mm/s) | 530 |
| Load centers distance(mm) | 500 | Max. Traction force(kN) | 15 |
| Lifting height(mm) | 3000 | Max. Gradeability(°) | 20 |
| Free lifting height(mm) | 140 | Deadweight (kg) | 3440 |
| Tilt Angle of Mast(α/β) | 6/12 | Front wheel | 7.00-12-12PR |
| Total length (L) | 3650 | Rear wheel | 6.00-9-10PR |
| Total width (W) | 1155 | Wheel track (F/R) (W1/W2) (mm) | 965/980 |
| Fork (L×W×H) | 1070x122x40 | Engine Model | C490BPG |
| Load center distance (F/R)(mm) | 475/485 | Engine Rated power / speed (kW/r.p.m) | 40/2650 |
| Wheel base (L) | 1650 | Engine Max. torque / speed (N.w/r.p.m) | 160/1800-2000 |
Description :
The cab is opened on all sides for ventilation and operator's wider visual conveniences. It is equipped with sophisticated operating system, with widely used flow gear shift system.
Application:
This kind of forklift used for loading, unloading and stock filing of containers as well as other packages.
Advantage :
1. Physical appearance: Fork lift truck has brilliantly repeated streamline surface modeling and sharpening of shapes to required specification.
2. It has a luxurious appearance, flowing and richly dynamic lines of finishes.
3. It is equipped with high air-inflow silencing and extremely capable exhaust silencing technologies making sure that air in and around the engine is fresh crystal clean air.
4. Steering axle: It has less twisting hydraulic steering gear with transverse cylinder ensuring steering flexibility, maintenance simplicity and highly reliable.
