Log Yard Heavy Duty 8 Tons Forklift Flexible Steering 10800Kg Deadweight

China Log Yard Heavy Duty 8 Tons Forklift Flexible Steering 10800Kg Deadweight supplier

Large Image :  Log Yard Heavy Duty 8 Tons Forklift Flexible Steering 10800Kg Deadweight

Product Details:

Place of Origin: China
Brand Name: SINOMTP
Certification: ISO/CCC/BV
Model Number: XG580

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: Negotiation
Packaging Details: Nude, but with wax sprayed.
Delivery Time: 25 working days after received payment
Supply Ability: 500 units per month
Contact Now
Detailed Product Description
Model: XG580 Rated Lifting Capacity: 8000kg
Deadweight: 10800kg Minimum Turning Radius: 4200mm
Fork (L X W X H): 1600x180x80mm Minimum Ground Clearance: 180mm
High Light:

forklift loading truck

,

forklift lift truck

Log Yard Heavy Duty 8 Tons Forklift Flexible Steering 10800Kg Deadweight





Specification:



Model XG580 Distance from the center line of the Front axle to the fork surface (mm) 747
Rated lifting capacity (kg) 8000 Maximum Lifting Height(mm) 3000
Deadweight (kg) 10800 Free Lifting Height(mm) 160
Minimum turning radius (mm) 4200 Minimum Ground Clearance(mm) 180
Fork: L x W x H(mm) 1600x180x80 Track (Front/rear)(mm) 1494/1600
Overall Dimensions (LxBxH) (mm) 5257x2066x2715 Front tyre 4x8.25-20-14PR
Maximum Travel Speed (km/h) 26 Rear tyre 2x9.00-16-14PR
Gradeability (%) 20 Engine Model LR6108G6B
Load Center Distance(mm) 600 Engine Rated Power/Speed( kw/r • p • m) 81/2300
Tilt Angle of Mast (F/B) (°) 6°/12° Engine Max. Torque/Speed (N • m/r • p • m) 393/1600-1800
Wheelbase (mm) 2700




Description:



The forklift truck has heavy duty torque converter installed for smooth rotation of power within the internal combustion engine, to rotating driven load. Torque converter supersedes the mechanical clutch, effectively allowing the load to be configured from the power source.



Application:



Our 8 tons forklift truck is our latest modified equipment. It is widely applied in logistics operation like port, wharf, industrial and mining enterprises, stockyards and warehouses, construction site, and log yard.



Advantage:



1. Steering axle has less twisting hydraulic steering gear with transverse cylinder ensuring steering flexibility, maintenance simplicity and highly reliable

2. In-built with innovative, high quality gearbox and torque converter. Flexible internal transmission flow providing efficiency, reliable, stable and entire machine's operation conveniences.

3. Brake system: air-over-oil brakes of good reliability with brake master cylinder and brake light.

4. The fork width is adjustable and is done by internal hydraulic system.
