Mechanical SDLG G9190 Grader Road Machinery Equipment Rear Axle Drive

China Mechanical SDLG G9190 Grader Road Machinery Equipment Rear Axle Drive supplier
Mechanical SDLG G9190 Grader Road Machinery Equipment Rear Axle Drive supplier Mechanical SDLG G9190 Grader Road Machinery Equipment Rear Axle Drive supplier

Large Image :  Mechanical SDLG G9190 Grader Road Machinery Equipment Rear Axle Drive

Product Details:

Place of Origin: China
Brand Name: SINOMTP
Certification: ISO/CCC
Model Number: G9190

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: Negotiation
Packaging Details: Nude
Delivery Time: 30 work days
Supply Ability: 100 units/month
Contact Now
Detailed Product Description
Model: G9190 Engine: DDE BF6M1013FC
Dimension: 8975x2710x3240 Rated Power: 148kW
Cabin: FOPS/ROPS Operating Weight (kg): 15800
High Light:

road construction machinery

,

road construction safety equipment

Mechanical SDLG G9190 Grader Road Machinery Equipment Rear Axle Drive





Specification:



Model G9190 Brake system Chain transmission drum brake
Engine DDE BF6M1013FC Driving type Rear axle drive
Rated Power 148kW Dimension (LxWxH)(mm) 8975x2710x3240
Transmission type ZF6WG200 Gearbox Standard operating weight (kg) 15800
Drive Axle Meichi Axle Cabin FOPS/ROPS
Hydraulic system Mechanical operation Blade Dimension(mm) --



Description:



G9190 is a product of high speed, high efficiency, high accuracy and multiple purposes developed by SDLG on the basis of advanced technology of VOLVO, can be used for ground leveling and grooving, scraping slope, bulldozing, ploughing snow, loosening, compacting, material arrangement and mixing works, and is widely applied in construction operating condition of road, airport, defense engineering, mine construction, road construction, water conservancy construction and farmland improvement and so on.



Advantage:



1. FOPS/ROPS cab is safe and reliable and of good sealing performance; tt has wide visual field and is conductive to observe the condition of two ends of shovel nose tool in turning, crabbing and leveling rim angle, with high operational accuracy.

2. Swing frame is made of lubrication-free and maintenance-free composite bearing, with small frictional coefficient, high reliability and is shock-proof and wear-proof; Hydraulic lock cylinder location is adopted and is easy to operate.

3. Shovel nose tool structure and cylinder is reasonably arranged, with high levelness in operation.

4. Electrical system of the entire machine has centralized control, three-stage alarm electronic monitoring system, digitalized stepping instrument display, high man-machine interaction and is convenient for detection and maintenance; the entire machine control has automatic cruise function, which can get engine operated in setting speed and thus reduces the labor strength of operation person.

Mechanical SDLG G9190 Grader Road Machinery Equipment Rear Axle Drive
