Product Details:
Payment & Shipping Terms:
|
| Model: | XG515 | Rated Lifting Capacity: | 15000kg |
|---|---|---|---|
| Deadweight: | 20000kg | Fork (L X W X H): | 1800x180x90mm |
| Tilt Angle Of Mast (F/B): | 6° /12° | Engine Fuel Consumption Rate: | 228g/kw.h |
| High Light: | forklift loading truck,forklift lift truck |
||
Low Fuel Consumption Industrial Forklift Truck 228G / Kw.H With Adjustable Spread Range
Specification:
| Product | XG515 | Max. Lifting Height(mm) | 3500 |
| Rated Lifting Capacity(kg) | 15000 | Free Lifting Height(mm) | 180 |
| Deadweight(kg) | 20000 | Minimum Ground Clearance(mm) | 250 |
| Fork: L x W x H(mm) | 1800x180x90 | Track (Front/rear)(mm) | 2060/2330 |
| Minimum Turning Radius(mm) | 5800 | Wheelbase(mm) | 3800 |
| Overall Dimensions(LxBxH)(mm) | 7360x2750x3600 | Front tyre | 4-12.00-24/18PR |
| Travel Speed: Forward 1-2/Backward (km/h) | 10-25/12.5 | Rear tyre | 2-12.00-20/16PR |
| Gradeability (%) | 20 | Engine Model | D6114ZG9B |
| Load Center Distance(mm) | 600 | Engine Rated Power/ Speed (kw/r • p • m)) | 125/2200 |
| Tilt Angle of Mast (F/B)( °) | 6° /12° |
Engine Max. Torque Speed (N • m/r • p • m) |
650/1400
|
| Fully-loaded Lifting Speed (mm/s) | 300 | Engine Fuel Consumption Rate (g/kw.h) | 228 |
Description:
Fitted with handy steer with maximum freedom, provides steering conveniences. High strength solid steel gantry fork fixed with fork with regulator.
Application:
Widely used in logistics operation sites like port, wharf, industrial and mining enterprises, station and warehouse, construction site, log yard and much more.
Advantage:
1. The transmission mode is hydraulic transmission (flexible transmission), being stable and convenient to operate.
2. Brake system is famous brand product, with reliable brake performance.
3. CPCD150 fork spread can be adjusted by hydraulic system, which will make the operation easier and reduce the labor intensity.
