3500kg FD35 Industrial Forklift Truck Diesel Power Source 1070×125×45mm

China 3500kg FD35 Industrial Forklift Truck Diesel Power Source 1070×125×45mm supplier

Large Image :  3500kg FD35 Industrial Forklift Truck Diesel Power Source 1070×125×45mm

Product Details:

Place of Origin: China
Brand Name: SINOMTP
Certification: ISO/CCC/BV/CE
Model Number: SINOMTP-FD35

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: Negotiation
Packaging Details: Nude, but with wax sprayed.
Delivery Time: 25 working days after received payment
Supply Ability: 500 units per month
Detailed Product Description
Model: SINOMTP-FD35 Power Source: Diesel
Rated Load Capacity: 3500kg Fork Size (L×W×T): 1070×125×45mm
Engine Brand Tilt(F/R): ISUZU Displacement: 2369cc

3500kg FD35 Industrial Forklift Truck Diesel Power Source 1070×125×45mm





Specification:



Type of model FD35
Power source Diesel
Rated load capacity 3500kg
Load centre 500mm
Lift height 3000mm
Fork size (L×W×T) 1070×125×45mm
Fork carriage tilt(F/R) 6°/12°
Overall Length(Length to fork face) 2710mm
Overall Width 1225mm
Mast Lowered Height 2045mm
Mast Extended Height 4150mm
Overhead Guard Height 2090mm
Gradeability(Laden) 20%
Front Tire 28×9-15-12PR
Rear Tire 6.50-10-10PR




Description:



Brand ISUZU
Model C240PKJ
Rated output 35.4/2500kw/r.p.m
Rated torque 139/1800Nm/r.p.m
No. of cylinder 4
Bore x Stroke 86X102mm
Displacement 2369cc



Advantage:



1. Designed according to ergonomic principles, makes operation much comfortable and also relieves the fatigue.

2. Wide-view mast gives the operator an enhanced forward visibility, which adds to the efficiency and safety of operator.

3. The instruments offer an easy accesses to the working condition of the truck, thus makes handling process more efficient and safe.

4. The powerful engine ensures SINOMTP truck’s high handling performance and offers an intrinsical safety and efficient operation.

3500kg FD35 Industrial Forklift Truck Diesel Power Source 1070×125×45mm
