Product Details:
Payment & Shipping Terms:
|
| Model: | XG6121D | Engine: | Cummins 6BT5.9 |
|---|---|---|---|
| Operating Weight (kg): | 12000 | Engine Rated Power (KW): | 112 |
| Centrifugal Force (KN): | 40/162 | Theoretical Amplitude (mm): | 0.42/0.9 |
| High Light: | road machinery equipment,road construction safety equipment |
||
Specification:
| Model | XG6121D | 1 gear (km/h) | 0-10 |
| Engine Model | Cummins 6BT5.9 | Rated Speed (r/min) | 2400 |
| Operating Weight (kg) | 12000 | Engine Rated Power (KW) | 112 |
| Drum(D×W) (mm) | φ1250×2130 | Vibration Frequency (Hz) | 30;35;45 |
| Min. Turning Radius (mm) | 6500 | Drum Weight (kg) | 5900 |
| Max. Gradeability (%) | 30 | Centrifugal Force (KN) | 40/162 |
| Theoretical Amplitude (mm) | 0.42/0.9 |
Overall Dimensions (L×W×H) (mm) |
5189×2280×3288 |
Description:
To ensure the quality of our road roller, we use SAUER or REXROTH pumps, motors, Sweden SKF or Germany FAG vibratory bearings.
Advantage:
Application:
This type road roller used for compacting the asphalt road surface.
