| Model: | XG6261P | Engine: | Cummins 6BT5.9 |
|---|---|---|---|
| Operating Weight (kg): | 26000 | Compaction Width (mm): | 2750 |
| Wheelbase (mm): | 3860 | Engine Power (KW): | 105 |
| High Light: | road construction machinery,road machinery equipment |
||
Specification:
| Model | XG6261P | Min. Ground Clearance (mm) | 300 |
| Engine Model | Cummins 6BT5.9 | Min. Turning Radius (mm) | 9000 |
| Max. Operating Weight (kg) | 26000 | Gradeability (%) | 20 |
| Weight of Counter weighted Water (kg) | 3000 | Ground Specific Pressure (kPa) | 200-360 |
| Weight of Counter weighted Iron (kg) | 4500 | Wheelbase (mm) | 3860 |
| Min. Operating Weight (kg) | 18500 | Engine Power (KW) | 105 |
| Compaction Width (mm) | 2750 | Overall Dimensions (L×W×H) (mm) | 4906×2800×3430 |
Description:
It can adjust the operating weight and the air pressure of the inflated tyres to change its compacting performance for a wide scope of application.
Advantage:
Application:
It is designed and built for compacting high grade asphalt road surface, mixed earth.
