Product Details:
Payment & Shipping Terms:
|
| Engine Model: | Shangchai SC8D156G2B1 | Compacting Width (mm): | 2750 |
|---|---|---|---|
| Front/rear Tire Overlap (mm): | 50 | Shangchai SC8D156G2B1: | 527 |
| Weight Of Water Counterweights (kg): | 2900 | Weight Of Counterweight Blocks (kg): | 10900 |
| High Light: | road construction machinery,road machinery equipment |
||
Shantui SR26T wheel road roller with 30000kg max. operating weight for compaction
Specification:
| Model | SR26T | Compacting width (mm) | 2750 |
| Length × width × height (mm) | 5060×2892×3338 | Front/rear tire overlap (mm) | 50 |
| Minimum operating weight | 16200 | Front wheel oscillation (mm) | ±50 |
| Maximum operating weight (kg) | 30000 | Gradeability (%) | 20 |
| Weight of counterweight blocks (kg) | 10900 | Engine model | Shangchai SC8D156G2B1 |
| Weight of water counterweights (kg) | 2900 | Static linear load (N/cm) | 527 |
Description:
The compacting performance can be improved by changing the load and pressure of inflated tires.
Advantage:
1.The design of streamline hood works with two-sided operation and wide-angle rear view mirrors to provide the operator with a broad visual field.
2.The spacious and bright cab can be equipped with optional heating and air conditioning system depending on different working environments.
3.The intermittent water sprinkling system is adopted to meet the demands of diversified working conditions, effectively use the water pump, prolong the service life of water pump, and improve the working efficiency.
4.Two brake systems (emergency brake system and handbrake) ensure the safety of personnel and machine during working.
Application:
This machine is applicable for the compacting of sub-base layer.
