Product Details:
Payment & Shipping Terms:
|
| Type: | Linear Vibrating Screen | Model: | MTP 0612 |
|---|---|---|---|
| Screening Area (m2): | 0.6X1.2 | Amplitude (mm): | 2~4 |
| Motor Model: | YZS-3-6 | Motor Power (kW): | 0.25 |
| Rotating Speed (r/min): | 970 | ||
| High Light: | construction mining equipment,mining safety equipment |
||
Linear Vibrating Screen with mesh made of wear-resistant rubber with long service life
Specification:
| Type | Linear Vibrating Screen |
| Model | MTP 0612 |
| Screening Area (m2) | 0.6X1.2 |
| Amplitude (mm) | 2~4 |
| Motor Model | YZS-3-6 |
| Motor Power (kW) | 0.25 |
| Rotating Speed (r/min) | 970 |
Product Introduction:
A vibrating screen that screen box takes reciprocating movement along the directional linear, is used for fine screening.
Product Improvement:
Screen angle is adjustable
Vibrating motor as vibration exciter, low energy consumption
Advantages:
Work Principle:
When linear vibrating screen works, the two motor reversely placed synchronously generate reverse force, which forces the screen body do the vertical motion. The materials on vibrating screen under the exciting force are periodically thrown forward to finish screening.
