Product Details:
Payment & Shipping Terms:
|
| Production: | Vertical Roller Mill | Wheel Diameter: | 2200mm |
|---|---|---|---|
| Output: | 35-50 Th | Out Of The Mill Air Temperature: | 75-95℃ |
| Raw Coal Hard Grove Grind Ability Index: | >55 HGI | Main Motor Power: | 500kw |
| High Light: | crushing stone machine,rock crushing machines |
||
35-50 Th Output Vertical Coal Mill 2200 Wheel Diameter 500Kw Motor Power
Specification:
| Production | Vertical Roller Mill |
| Wheel diameter(mm) | 2200 |
| Output (th) | 35-50 |
| Coal powder fineness (R0.08) | 5~20% |
| End product moisture (%) | <1% |
| Grinding material particle size D80 (mm) | <10 |
| Grinding material max feed size(mm) | <50 |
| Material moisture of into mill (%) | <15% |
| Into mill air temperature (℃) | <350 |
| Out of the mill air temperature (℃)) | 75-95 |
| Raw coal hard grove grind ability index (HGI) | >55 |
| Main motor power (kw) | 500 |
Description:
According to customers’ requirements, We success in absorbing foreign experience and world-advanced technology, and in producing our vertical products, with self-owned intellectual property right. Now it has wide application in metallurgy, construction, chemical and mining industries, being the preferred equipment in grinding industry.
Advantage:
1. Small occupation area Low investment cost
2. Low operation cost and long service life
3. High grinding efficiency
4. Excellent drying function
5. Good final products quality
6. Easy to maintain
7. Environmentally friendly
8. High classifying capacity
Application:
Vertical Roller Mill are widely used in grinding non-flammable and non-explosive materials under 9.3(the Moh's hardness), such as grinding quartz.
