Product Details:
Payment & Shipping Terms:
|
| Production: | Ultra-fine Mill | Working Diameter: | Φ900mm |
|---|---|---|---|
| Max.Feed Size: | ≤20 Mm | Main Motor Power: | 45×2 |
| Crusher: | PC400×600 | Elevator: | TH-200 |
| High Light: | rock crushing machines,stone crushing machine |
||
SCM Super-micro mill used to produce fine powder and super fine powder
Specification:
| Production | Ultra-fine Mill |
| Working diameter (mm) | Φ900 |
| Max feed size (mm) | ≤20 |
| Final size (mesh) | 325-2500 |
| Output (kgh) | 800-6500 |
| Main motor Power | 45×2 |
| Analytical engine (FM motor) Power | 18.5 |
| Blower motor Power | 55 |
| Crusher | PC400×600 |
| Elevator | TH-200 |
| Vibrating feeder |
300×60 upon belt conveyor |
| Discharge screw conveyor | LS219×5.8 |
| Discharge valve |
ZJD-200 ZJD-250 |
| Pulse dust collectors | DMC160 |
| Air compressor | KSH240D |
Description:
SCM series ultra-fine mill is specially designed for super fine powder grinding. Now it’s growing more and more popular with its reliable technology and perfect after-sale services.
Advantage:
1. High Output and low energy consumption
2. High fineness and flexible adjustment
3. Safe and Reliable
4. Clean and environmental friendly
Application:
SCM Super-micro mill is mainly used to produce fine powder and super fine powder. It is applicable to non-flammable and non-explosive materials with hardness less than 6, such as calcite, chalk, limestone, dolomite, kaolin, Benton, talcum, talc, magnetite, illicit, chlorophyll, vermiculite, politeness, etc.
