| Production: | Ultra-fine Mill | Working Diameter: | Φ1250mm |
|---|---|---|---|
| Max.Feed Size: | ≤20 Mm | Main Motor Power: | 55×2 |
| Crusher: | PC600x800 | Elevator: | TH-300 |
| High Light: | crushing stone machine,rock crushing machines |
||
SCM Ultra-fine Mill safe and reliable with high output and low energy consumption
Specification:
| Production | Ultra-fine Mill |
| Working diameter (mm) | Φ1250 |
| Max feed size (mm) | ≤20 |
| Final size (mesh) | 325-2500 |
| Output (kgh) | 2500-14000 |
| Main motor Power | 185 |
| Analytical engine (FM motor) Power | 37 |
| Blower motor Power | 55x2 |
| Crusher | PC600x800 |
| Elevator | TH-300 |
| Vibrating feeder |
400×80 Apon belt conveyor |
| Discharge screw conveyor | LS219×5 |
| Discharge valve | ZJD-250 |
| Pulse dust collectors | LDMC250×2 |
| Air compressor | KSH300D×2 |
Description:
SCM series ultra-fine mill is specially designed for super fine powder grinding. Now it’s growing more and more popular with its reliable technology and perfect after-sale services.
Advantage:
1. High Output and low energy consumption
2. High fineness and flexible adjustment
3. Safe and Reliable
4. Clean and environmental friendly
Application:
SCM Super-micro mill is mainly used to produce fine powder and super fine powder. It is applicable to non-flammable and non-explosive materials with hardness less than 6, such as calcite, chalk, limestone, dolomite, kaolin, Benton, talcum, talc, magnetite, illicit, chlorophyll, vermiculite, politeness, etc.
