SHANTUI HBT6014 pump trailer adopts PLC control system and integrated switching power supply

China SHANTUI HBT6014 pump trailer adopts PLC control system and integrated switching power supply supplier

Large Image :  SHANTUI HBT6014 pump trailer adopts PLC control system and integrated switching power supply

Product Details:

Place of Origin: China
Brand Name: SINOMTP
Certification: ISO/CE/BV/CCC
Model Number: HBT6014

Payment & Shipping Terms:

Minimum Order Quantity: 1 unit
Price: Negotiation
Packaging Details: NUDE
Delivery Time: 35 days before payment
Supply Ability: 50 units per month
Contact Now
Detailed Product Description
Maximum Theoretical Pumping Capacity: 70~38m3 Maximum Theoretic Output Pressure: 7~13.5MPa
Concrete Distribution Valve: “S” Valve Concrete Slump Range: 80~230mm
Bore × Travel Of Pumping Cylinder: Φ200x1800mm Bore × Travel Of Main Cylinder: Φ130x1800mm
High Light:

construction machinery equipment

,

industrial construction equipment

SHANTUI HBT6014 pump trailer adopts PLC control system and integrated switching power supply



Model

HBT6014
Pumping system Maximum theoretical pumping capacity m3 70~38
Maximum theoretic output pressure MPa 7~13.5
Concrete distribution valve   “S” valve
Concrete slump range mm 80~230
Bore × travel of pumping cylinder mm Φ200x1800
Bore × travel of main cylinder mm Φ130x1800
Hopper capacity/loading height L/mm 800/1470
Maximum aggregate size mm 40(125A)
Power system Power/speed kW/r/min 90/1480
Other Gross weight Kg 6300
Overall dimensions (L×W×H) mm 6530x2110x2260



Description:

The diesel engine installed is suitable for the projects with insufficient electric power supply. The diesel engine adopts Weichai Deutz diesel engine, featuring strong power and prominent performance.

Advantage:

1. The dual-pump dual-circuit open-loop hydraulic system and the highly integrated electro-hydraulic control valve group are adopted to ensure low reversing impact and stable and reliable motions.

2. The master oil pump, constant pressure pump, and hydraulic control units adopt originally imported products from world’s renowned brands, with automatic over-pressure cutoff device, featuring reasonable structure and powerful performance.

3. The electronic control system adopts PLC control system and integrated switching power supply, featuring advanced, reliable, simple, and practical technologies. ;

4. The S-pipe valves are made of high wear-resistant materials with advanced manufacturing processes to promote service life.



SHANTUI HBT6014 pump trailer adopts PLC control system and integrated switching power supply
