|Maximum Theoretical Pumping Capacity:||90~52m3||Maximum Theoretic Output Pressure:||10~18MPa|
|Concrete Distribution Valve:||“S” Valve||Hopper Capacity/loading Height:||800/1470L/mm|
|Maximum Aggregate Size:||40(125A)mm||Power/speed:||195/2000kW/r/min|
SHANTUI HBT9018R concrete pump trailer adopts Weichai Deutz diesel engine
|Model||HBT9018R Trailer Pump Series||Unit||Specification|
|Pumping system||Maximum theoretical pumping capacity||m3||90~52|
|Maximum theoretic output pressure||Mpa||10~18|
|Concrete distribution valve||“S”|
|Concrete slump range||mm||80~230|
|Bore × travel of pumping cylinder||mm||Φ200x1800|
|Bore × travel of main cylinder||mm||Φ150x1900|
|Hopper capacity/loading height||L/mm||800/1470|
|Maximum aggregate size||mm||40(125A)|
|Overall dimensions (L×W×H)||mm||7185×2056×2635|
1. The dual-pump dual-circuit open-loop hydraulic system and the highly integrated electro-hydraulic control valve group are adopted to ensure low reversing impact and stable and reliable motions.
2. The master oil pump, constant pressure pump, and hydraulic control units adopt originally imported products from world’s renowned brands, with automatic over-pressure cutoff device, featuring reasonable structure and powerful performance.
3. The electronic control system adopts PLC control system and integrated switching power supply, featuring advanced, reliable, simple, and practical technologies.
4. The S-pipe valve is adopted, in which the S-pipe is bead welded from imported wear-resistant welding rods and the shaft end is treated by nitriding of high strength alloy steel to prevent the rupture of shaft end and promote its service life. The wearing plate and the cutting ring are made of wear-resistant hard alloy to remarkably improve the service life.
5. New mixing mechanism and reasonably designed shaft end seals make the maintenances easier and the optimized hopper structure eliminates the dead spaces for material deposit and promotes the concrete suction efficiency.
6. The automatic retraction function of concrete piston can retract the concrete piston to the washer chamber to greatly ease the checking, repair, and replacement of the concrete piston.
7. It's equipped with high/low pressure switching function to ease the choice of pumping mode depending on the working condition.
