Sinomtp Gravity Separation Equipment Spiral Chute 900, 720, 540mm Screw Pitch

China Sinomtp Gravity Separation Equipment Spiral Chute 900, 720, 540mm Screw Pitch supplier
Sinomtp Gravity Separation Equipment Spiral Chute 900, 720, 540mm Screw Pitch supplier Sinomtp Gravity Separation Equipment Spiral Chute 900, 720, 540mm Screw Pitch supplier

Large Image :  Sinomtp Gravity Separation Equipment Spiral Chute 900, 720, 540mm Screw Pitch

Product Details:

Place of Origin: China
Brand Name: SINOMTP
Certification: ISO/CCC
Model Number: BLL-1200

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: Negotiation
Packaging Details: Nude
Delivery Time: 30 work days
Supply Ability: 100 units/month
Contact Now
Detailed Product Description
Type: Gravity Separation Equipment Spiral Chute Model: BLL-1200
Outside Diameter (mm): 1200 Screw Pitch (mm): 900, 720, 540
Pitch Diameter Ratio: 0.75, 0.6, 0.45 Lateral Dip Angle (degree):
Max. Screw Numbers Per Set: 4 Feed Size (mm): 0.3~0.03
High Light:

construction mining equipment

,

mining safety equipment

Sinomtp Gravity Separation Equipment Spiral Chute 900, 720, 540mm Screw Pitch



Specification:



Model BLL-1200
Outside Diameter (mm) 1200
Screw Pitch (mm) 900, 720, 540
Pitch Diameter Ratio 0.75, 0.6, 0.45
Lateral Dip Angle (degree)
Max. Screw Numbers Per Set 4
Feed Size (mm) 0.3~0.03
Feed Density (%) 25 ~55
Capacity (t/h) 4~6
Overall
Dimension
Length (mm) 1360
Width (mm) 1360
Height (mm) 5230
Weight (kg) 700/650/600



Description:



A gravity separation equipment of separation different weight mineral by inertial centrifugal force pulp produced in helix turning motion.There are 3 kinds of chute for user to choose, glass steel chute, wear-resistant rubber liner, polyurethane rubber liner.



Work Principle:



1.Ore pulps are uniformly fed into machine and form different layers as they pass across chute. Heavy minerals precipitate to bottom and are moved toward inner edge by the comprehensive action of various forces; light minerals are moved toward outer inner due to the speedy rotation.

2.Spiral chute is suitable for treatment of 0.6-0.03mm lode and placer, but high mud content is bad for separation. At present, spiral chute has been widely used in the treatment of iron ore, tungsten, tin ore, niobium tantalum ore, coastal and riverside placer and gold ore.



Sinomtp Gravity Separation Equipment Spiral Chute 900, 720, 540mm Screw Pitch
