Product Details:
Payment & Shipping Terms:
|
| Productivity (m3/h): | Optional | Mixing Power (kW): | Optional |
|---|---|---|---|
| Discharge Capacity (m3): | Optional | Maximum Aggregate Size (gravel/pebble Mm): | Optional |
| Bin Capacity(m3): | Optional | Winch Motor Power(kW): | Optional |
| High Light: | construction machinery equipment,industrial construction equipment |
||
SHANTUI HZN40, HZS50, HZS75, HZS100, and HZS150 Special Batching Plants with different Productivity
| Item | HZN40D | HZS50D | HZS75D | HZS100D | HZS150D | ||
| Productivity (m3/h) | 40 | 50 | 75 | 100 | 150 | ||
| Main mixing unit | Model | JN750 | JS1000 | JS1500 | JS2000 | JS3000 | |
| Mixing power (kW) | 30 | 2×18.5 | 2×30 | 2×37 | 2×55 | ||
| Discharge capacity (m3) | 0.75 | 1 | 1.5 | 2 | 3 | ||
| Maximum aggregate size (gravel/pebble mm) | ≤60/80 | ≤60/80 | ≤60/80 | ≤60/80 | ≤60/80 | ||
| Material bin | Bin capacity(m3) | 4 | 8 | 8 | 20 | 20 | |
| Winch motor power(kW) | 7.5 | 18.5 | 22 | 30 | 45 | ||
| Weighing range and metering accuracy | Aggregate (kg) | 1500±2% | 2000±2% | 3000±2% | 4000±2% | 6000±2% | |
| Cement (kg) | 400±1% | 500±1% | 800±1% | 1000±1% | 1500±1% | ||
| Coal ash (kg) | --- | 150±1% | 200±1% | 400±1% | 600±1% | ||
| Water (kg) | Metering of turbine flowmeter | 200±1% | 300±1% | 400±1% | 600±1% | ||
| Additive (kg) | 20±1% | 20±1% | 30±1% | 40±1% | 60±1% | ||
| Discharge height (m) | 3.8 | 3.8 | 3.8 | 3.8 | 3.8 | ||
Description:
Product features: It features modular structure and easy equipment installation. It’s unnecessary to prepare additional foundation. This batching plant can be put into operation without foundation provided that hardness and levelness of the ground meet the equipment requirements.
Application:
Product application: It’s applicable for the engineering constructions of buildings, water conservancy projects, roads, ports, and buildings that require frequent site transfer and for the early stage concrete constructions of large projects.
