| Production: | Vibrating Feeder | Trough Size: | 1100×3900mm |
|---|---|---|---|
| Max Feeding Size: | 600mm | Capacity(T/H): | 150-350 |
| REV: | 750-900 R/min | Power: | 2x55kw |
| High Light: | crushing stone machine,rock crushing machines |
||
Vibrating Feeder used in mining industries and building construction etc
Specification:
| Production | Vibrating feeder |
| Trough Size(mm) | 1100×3900 |
| Max Feeding Size(mm) | 600 |
| Capacity(T/H) | 150-350 |
| REV(r/min) | 750-900 |
| Power(KW) | 15 |
| Machine Size(mm) | 3980×2276×1953 |
Description:
Base on decades of years’ experience and thousands of clients’ production experience, SBM updated our traditional vibrating feeder and developed the TSW series feeder, which can greatly improve the whole production line capacity.
Advantage:
1. Benefit from its strong vibration exciter and two-steps grids design, the handling capacity is greatly increased.
2. Because of the adoption of converter control equipment, the feeding capacity can be controlled exactly.
3. The TSW feeder use updated material and structure design, so the service life is quite long and the it’s easy to maintain.
4. The two-stepped grids can screen the raw minerals directly, reducing the handling capacity of flowing crushers. As a result, the whole production line capacity can be greatly increased.
Application:
Series vibrating feeders are widely used in metal ore mining industries, building construction, solid waste management and cement industry and many other industries.
