Product Details:
Payment & Shipping Terms:
|
| Production: | Sand Washing Machine | Screw Diameter: | 920mm |
|---|---|---|---|
| Tank Length: | 7585 Mm | Max Feeding: | ≤10 Mm |
| REV: | 21 R/min | Motor Model: | Y160L-6/11 |
| High Light: | crushing stone machine,stone crushing machine |
||
Sand washer with high capacity and less loss of fine products and long service life
Specification:
| Production | Sand Washing machine |
| Screw Diameter (mm) | 920 |
| Tank Length (mm) | 7585 |
| Screw Quantity | 1 |
| Max Feeding (mm) | ≤10 |
| Capacity (t/h) | 100 |
| REV (r/min) | 21 |
| Power (kw) | 6-11 |
| Motor Model | Y160L-6/11 |
| Water Consumption (t/h) | 10-80 |
| Machine Size (mm) | 8420×2180×3960 |
Description:
Screw sand washing machine is designed to bigger capacity and higher cleaning level than traditional washing machines. It sets three functions—washing, dewatering, classifying—as a whole, saving the labor and working site space. Now this series sand washing machine has been widely used in various industries.
Advantage:
1. Long service life and no quick-wear part, leading to low investment cost and operation cost
2. High capacity and less loss of fine products
3. Transmission bearings of impeller depart from water and material, avoiding being eroded.
4. Higher washing-cleanliness than traditional ones
5. Set functions as a whole, reducing investment costs of other machines
Application:
LSX screw sand washing machine is used to remove the dust in sand. It is widely used for cleaning materials in the following industries: quarry, minerals, building materials, transportation, chemical industry, water conservancy and hydro power, cement mixture station and so on.
