2 Layers Vibrating Screen Machine 2100×6000 mm 7-11 mm D - Amplitude

China 2 Layers Vibrating Screen Machine 2100×6000 mm 7-11 mm D - Amplitude supplier

Large Image :  2 Layers Vibrating Screen Machine 2100×6000 mm 7-11 mm D - Amplitude

Product Details:

Place of Origin: China
Brand Name: SINOMTP
Certification: ISO/CCC
Model Number: Vibrating Screen

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: Negotiation
Packaging Details: Nude
Delivery Time: 30 work days
Supply Ability: 100 units/month
Detailed Product Description
Production: Vibrating Screen Screen Size: 2100×6000 Mm
Layers: 2 Mesh Size: 6~150 Mm
Angle: 20° D-Amplitude: 7~11 Mm

2 Layers Vibrating Screen Machine 2100×6000 mm 7-11 mm D - Amplitude





Specification:



Production Vibrating Screen
Screen Size(mm) 2100×6000
Layers 2
Mesh Size(mm) 6~150
Feeding Size(mm) 400
Capacity(t/h) 100~600
Power (kw) 30
D-Amplitude(mm) 7~11
Angle(°) 20



Description:



Depend on decades-years’ experience in mining industry and latest technology, SINOMTP designed the This series vibrating screen, which has high-strength exciting force. That series vibrating screen adopts the eccentric vibration exciter of N series. And the transmission adopts flexible connector. As a result, the amplitude is bigger and the vibration is much more stable than old types. Also the throughput and screening efficiency are greatly improved.



Advantage:



1. The exciter adopt outer eccentric block, the weight is light and the exciting force is strong. Operators can easily adjust the amplitude and exciting force by changing the eccentric blocks quantity.

2. The vibration exciter is fixed on the side-bar of screen box and two exciters are connected by universal coupling, so it is very easy to install and maintain.

3. For the transmission adopts flexible connector, there is no force transmit along the main shaft and it ensures the stable performance.



Application:



vibrating Screen is widely used for grading and screening materials in the following fields: minerals, quarry, building materials, water conservancy and hydro power, transportation, chemical industry, smelting and so on. For material quality of screen mesh is changeable, the application is quite extensive.
