4.5km / h Hydraulic Crawler Excavator SDLG LG6360E 37800kg Overall Operating Weight

China 4.5km / h Hydraulic Crawler Excavator SDLG LG6360E 37800kg Overall Operating Weight supplier

Large Image :  4.5km / h Hydraulic Crawler Excavator SDLG LG6360E 37800kg Overall Operating Weight

Product Details:

Place of Origin: CHINA
Brand Name: SINOMTP
Certification: ISO, CCC, BV
Model Number: LG6360E

Payment & Shipping Terms:

Minimum Order Quantity: 1 UNIT
Price: Negotiable
Packaging Details: nude
Delivery Time: 35 working days
Supply Ability: 100 units per month
Contact Now
Detailed Product Description
Engine: SD130A Engine Power: 198 Kw , Diesel
Overall Operating Weight: 37800kg Bucket Capacity: 1.7M3
Traveling Speed: 3.3/4.5km/h Dimension: 11020*3340*3350mm
Max Digging Radius: 11130mm
High Light:

hydraulic shovel excavator

,

crawler hydraulic excavator

4.5km / h Hydraulic Crawler Excavator SDLG LG6360E 37800kg Overall Operating Weight







Engine SD130A Working device Standard rod
Overall operating weight 37800kg Bucket capacity 1.7 m³
Max. digging force 198KN Swing speed 9.7 r/min
Traveling speed 3.3/4.5km/h Dimension 11020*3340*3350mm
Max digging radius 11130mm Max digging depth 7450mm
Max digging height 7290mm Engine rated power 198 kw
Length of boom 6450mm Max climbing angle 35°
Hydraulic system Pilot operation negative flow Cabin fog cabin mounted



Description:

The LG6360E is the product of SDLG’s absorbing advanced Volvo technologies to conduct a comprehensive upgrade and update, featuring strong power and efficient operation.



Advantage:

  1. Applied with the reinforced heavy-duty boom, and the mining-type arm and bucket, more reliable and better adapted to heavy-duty mining and other operating conditions,
  2. The high-torque slewing motor and reinforced slewing inner ring gear enable highslewing speed, and the wet brake ensures goods moothness and high reliability.
  3. Applied with the reinforced upper frame designed for harsh mining conditions and the X-type lower frame of the widened chassis, offering higher stability and easily qualified for heavy-duty operating conditions.
  4. The cab is bright and spacious, features wide vision and good sealing effect, and is equipped with the high -end shock absorbing seat, two-stage filtration A/C and silicone oil rubber shock absorber with excellent damping effect; all of them offer a comfortable riding environment.



Application:

Excavator is a multipurpose machinery of earthwork construction, mainly for digging and loading.

4.5km / h Hydraulic Crawler Excavator SDLG LG6360E 37800kg Overall Operating Weight
