Product Details:
Payment & Shipping Terms:
|
| Operating Weight: | 18100kg | Engine: | LR6A3Z-20 |
|---|---|---|---|
| Engine Power: | 160hp | Blade Type: | Straight Tilt |
| Blade Width * Height: | 4210x1021mm | Blade Capacity: | 4.39 CBM |
| High Light: | shantui construction machinery,dozer construction equipment |
||
18t operating weight XGMA bulldozer XG4160S model,suitable to swamp and soft land
Specification:
| Model | XG4160S | Engine model | LR6A3Z-20 |
| Operating weight | 18100kg | Main ground Clearance | 510 mm |
| Min turning radius | 4.3m | Grade ability | 30° |
| Blade type | Straight tilt | Blade capacity | 4.39 m³ |
| Blade width * height | 4210x1021mm | Max Depth | 426 mm |
| Track type | Sealed, assembled single-grouser | Number of track shoes | 44 (each side) |
| Width of Track shoes | 1070mm |
Flywheel horse power |
160hp |
| Final drive capacity | 33 L (each side) | Hydraulic Tank Capacity | 320 L |
Description:
Industry-leading driving force, efficient work, Sensitive and reliable manipulation, easy to maintain.
Advantages:
1. Awarded the ISO9001:2000 system certificate
2. Engine model: WEICHAI WD10G175E15
3. Flywheel horsepower: 160 HP (120 KW)/1850RPM
4. Operating weight (straight-tilt dozer): 18100kg
5. Made using KOMATSU D60P-8 bulldozer technology, XGMA bulldozer features high performance, great efficiency, safe and reliable operation
6. Taking the advantage of lower ground pressure, the bulldozer is suitable to be used in swamp and soft land application
7. Optional attachments: air conditioner, rubbish disposal blade.
Application:
Earth moving projects, bulldozing, digging, landfill, and other bulk operations.
