XG4181L bulldozer with 180hp Cummins engine , Angle blade and 18800kg operating weight

China XG4181L bulldozer with 180hp Cummins engine , Angle blade and 18800kg operating weight supplier

Large Image :  XG4181L bulldozer with 180hp Cummins engine , Angle blade and 18800kg operating weight

Product Details:

Place of Origin: CHINA
Brand Name: SINOMTP
Certification: ISO, CCC, BV
Model Number: XG4181L

Payment & Shipping Terms:

Minimum Order Quantity: 1 UNIT
Price: Negotiable
Packaging Details: Nude
Delivery Time: 35 working days
Supply Ability: 100 units per month
Contact Now
Detailed Product Description
Operating Weight: 18800kg Engine: CUMMINS NT855 C280S10
Engine Power: 180hp Blade Type: Angle Blade
Blade Width * Height: 3970x1050mm Blade Capacity: 4.3 Cbm
Max Lifting: 1250mm Ripper: Optional
High Light:

dozer construction equipment

,

heavy equipment bulldozer

XG4181L bulldozer with 180hp Cummins engine , Angle blade and 18800kg operating weight



Specification:

Model XG4181L Engine model

Cummins

NT855-C280S10

Blade type Angle blade Blade capacity 4.3 m³
Track gauge 1880 mm Track type Sealed, assembled single-grouser
Operating weight 19000kg Main ground Clearance 400 mm
Min turning radius 3.3m Grade ability 30°
Blade width * height 3970x1050mm Max Depth 545 mm
Max lifting 1250mm Working cylinder type Double-acting piston type
Width of Track shoes 510mm

Flywheel

horse power

180hp
Engine oil capacity 45L Hydraulic tank capacity 108L

3-shank ripper

Max.lift

702mm Max.digging depth 572mm





Description:

Industry-leading driving force, efficient work, Sensitive and reliable manipulation, easy to maintain.



Advantages:

1. Awarded the ISO9001:2000 system certificate

2. Engine model: CUMMINS NT855-C280S10 SHANGCHAI C6121ZG58 / WEICHAI WD10G200E15

3. Flywheel horsepower: 180 HP (135 KW)/1850RPM

4. Operating weight (straight-tilt dozer): 18800KG

5. Made using KOMATSU D65E-8 bulldozer technology, XGMA bulldozer features high performance, great efficiency, safe and reliable operation

6. The bulldozer is widely used in infrastructure and industries including large mining area, port, power plant, road building, etc.

7. Enlarged water tank and 3-stage air cleaning are available at customers' option for tropical and desert application.

8. Optional attachments: straight-tilt blade, angle blade, u-blade, ROPS cabin, canopy, 3-shank ripper, air conditioner, 510mm track shoes, 610mm track shoes.



Application:

Earth moving projects, bulldozing, digging, landfill, and other bulk operations.
