Product Details:
Payment & Shipping Terms:
|
| Operating Weight: | 23400kg | Engine: | Cummins NT855-C280S10 |
|---|---|---|---|
| Engine Power: | 180hp | Blade Type: | Straight Tilt Blade |
| Blade Width * Height: | 3725x1315mm | Blade Capacity: | 6.4 M3 |
| Max Depth: | 545mm | ||
| High Light: | shantui construction machinery,dozer construction equipment |
||
XGMA XG4220D bulldozer with Komatsu technology 220 hp Cummins engine and ROPS cabin optional
Specification:
| Model | XG4220D | Engine model |
Cummins NT855-C280S10 |
| Blade type | Straight tilt blade | Blade capacity | 6.4 m³ |
| Track gauge | 2000 mm | Track type | Sealed, assembled single-grouser |
| Operating weight | 23400kg | Main ground Clearance | 405 mm |
| Min turning radius | 3.3m | Grade ability | 30° |
| Blade width * height | 3725x1315mm | Max Depth | 540 mm |
| Max lifting | 1210mm | Working cylinder type | Double-acting piston type |
| Width of Track shoes | 510mm |
Flywheel horse power |
180hp |
| Engine oil capacity | 45L | Hydraulic tank capacity | 108L |
|
Single-shank ripper Max.lift |
520mm | Max.digging depth | 695mm |
Description:
Industry-leading driving force, efficient work, Sensitive and reliable manipulation, easy to maintain.
Advantages:
1. Awarded the ISO9001:2000 system certificate
2. Engine model: CUMMINS NT855-C280S10
3. Flywheel horsepower: 220 hp (162 kw)/1800rpm
4. Operating weight (u-blade): 24500kg
5. Made using the technology of KOMATSU D85A-18 bulldozer, XGMA bulldozer features high performance, great efficiency, safe and reliable operation
6. Mounted with enlarged water tank for effective cooling of engine and 3-stage air cleaning, the bulldozer is suitable for use in hot and desert area under severe working conditions
7. Optional attachments: straight-tilt blade, angle blade, u-blade, ROPS cabin, 3-shank ripper, single ripper, air conditioner.
Application:
Earth moving projects, bulldozing, digging, landfill, and other bulk operations.
