| Operating Weight: | 23400kg | Engine: | Cummins NT855-C280S10 |
|---|---|---|---|
| Engine Power: | 180hp | Blade Type: | "U" Type Blade |
| Blade Capacity: | 6.4 M3 | Grade Ability: | 30° |
| Max.digging Depth: | 695mm | Track Gauge: | 2000mm |
| High Light: | dozer construction equipment,heavy equipment bulldozer |
||
XGMA XG4220F bulldozer with 220hp Cummins engine 220hp , straight-tilt dozer
Spicification:
| Model | XG4220F | Engine model |
Cummins NT855-C280S10 |
| Blade type | Straight tilt blade | Blade capacity | 6.4 m³ |
| Track gauge | 2000 mm | Track type | Sealed, assembled single-grouser |
| Operating weight | 23400kg | Main ground Clearance | 405 mm |
| Min turning radius | 3.3m | Grade ability | 30° |
| Blade width * height | 3725x1315mm | Max Depth | 540 mm |
| Max lifting | 1210mm | Working cylinder type | Double-acting piston type |
| Width of Track shoes | 560mm |
Flywheel horse power |
220hp |
| Engine oil capacity | 45L | Hydraulic tank capacity | 108L |
|
Single-shank ripper Max.lift |
520mm | Max.digging depth | 695mm |
Description:
Industry-leading driving force, efficient work, Sensitive and reliable manipulation, easy to maintain.
Advantages:
1. Awarded the ISO9001:2000 system certificate
2. Engine model: CUMMINS NT855-C280S10
3. Flywheel horsepower: 220 hp (162 kw)/1800rpm
4. Operating weight (straight-tilt dozer): 23400kg
5. Manufactured using KOMATSU D85A-18 bulldozer technology, XGMA bulldozer features high performance, great efficiency, safe and reliable operation
6. The bulldozer is widely used in forestry logging applications
7. Optional attachments: angle blade, u-blade, 3-shank ripper, winch, single ripper, ROPS cab, canopy.
Application:
Earth moving projects, bulldozing, digging, landfill, and other bulk operations.
