Product Details:
Payment & Shipping Terms:
|
| Engine: | Shangchai C6121ZG55 | Dozer Capacity: | 4.5 M³ |
|---|---|---|---|
| Gradient: | 30°/25° | Number Of Track Rollers: | 7 Each Side |
| Number Of Carrier Rollers: | 2 Each Side | ||
| High Light: | dozer construction equipment,heavy equipment bulldozer |
||
HBXG SD6G bulldozer used CAT technique of hydraulic operation with shangchai engine
| Specifications | |||
| Dozer | Tilt | ||
| Operation weight | 16500 kg | ||
| Ground pressure | 52.80 kpa | ||
| Track gauge | 1880 mm | ||
| Min.ground clearance | 445 mm | ||
| Gradient | 30°/25° | ||
| Dozing capacity | 4.5 m³ | ||
| Blade width | 3297 mm | ||
| Max.digging depth | 592 mm | ||
| Overall dimensions | 5032x3297x3154 mm | ||
| Engine | |||
| Type | Shangchai C6121ZG55 | ||
| Rated revolution | 1900 rpm | ||
| Flywheel power | 119 kw | ||
| Max.torque | 810/14500 N.m/rpm | ||
| Rated fuel consumption | ≤215 g/kw.h | ||
| Undercarriage system | |||
| Type |
Swing type of sprayed beam. Suspended structure of equalizer bar. |
||
| Number of track rollers | 7 (each side) | ||
| Number of carrier rollers | 2 (each side) | ||
| Pitch | 203 mm | ||
| Width of shoe | 560 mm | ||
| Gear | 1st | 2nd | 3rd |
| Forward km/h | 0-4 | 0-6.9 | 0-10.8 |
| Backward km/h | 0-4.8 | 0-8.4 | 0-12.9 |
| Implement hydraulic system | |||
| Max.system pressure | 15.5 mpa | ||
| Pump type | Gears pump | ||
| System output | 167 L/min | ||
| Driving system | |||
| Torque converter | Hydraulic mechanical torque convertor with external power split | ||
| Transmission | Planetary, power shift transmission with three speeds forward and three speeds reverse, speed and direction can be quickly shifted. | ||
| Steering clutch | Multiple-disc oil power metallurgy disc compressed by spring, hydraulic operated | ||
| Steering brake | Brake is oil two direction floating band brake operated by mechanical foot pedal | ||
| Final drive | The final drive are double redution with spur gear and segment sprocket. | ||
Description:
SD6G bulldozer is 160 horsepower track-type dozer with hydraulic direct drive, semi-rigid suspended and hydraulic controls.
Applications:
It is an ideal machine used in communication, desert, oil field, power, mining etc large earth moving program.
Competitive advantage:
