Product Details:

Place of Origin: HEBEI
Brand Name: HBXG
Certification: ISO/FMRC/CCC
Model Number: TY165-2

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: NEGOTIATION
Packaging Details: Nude
Delivery Time: in 30 working days
Payment Terms: L/C, T/T
Supply Ability: 30 units per month
Contact Now
Detailed Product Description
Operating Weight(kg): 17550/18030 Ground Pressure(kpa): 68.3/70.1
Dozing Capacity M3: 4.6/5.2 Engine Type: Weichai
Overall Dimension: 5447*3442*3160 Min.Ground Clearance (mm): 352.5
High Light:

dozer construction equipment

,

heavy equipment bulldozer

HBXG TY165-2 Crawler Bullzoder Equipped With Weichai Engine And Characterized By High Efficient, Open View





SPECIFICATION:



Dozer Tilt/U-blade Undercarriage system
Operating Weight(kg) with riper 17550/18030 Type
Ground pressure(kpa) 68.3/70.1 Swing type sprayed beam
Track gauge (mm) 1880/1880 Suspended structure of equalizer bar
Gradient 30/25
Min.Ground clearance (mm) 352.5

N of track rollers

N of carrier rollers

6 for each side

2 for each side

Dozing capacity m3 4.6/5.2 Pitch (mm) 203
Blade width (mm) 3442/3467 Width of shoe (mm) 500
Max digging depth (mm) 420/377 Gears Forward
Overall dimension 5447*3442*3160 Backward
Engine Type Weichai Implement hydraulic system
Rated reverlation 1850 Max.system pressure 12 Mpa
Engine power (kw) 121 Pump type Two group Gears
Rated fuel consumption(g/kw.h) <215 System output (L/min) 185
Driving system
Torque converter 3-element 1-stage 1-phase
Transmission Planetary, power shift transmission with three speeds forwards and three speeds reverse, speed and direction can be quickly shifted
Steering clutch Multiple-disc oil power metallurgy disc compressed by spring, hydraulic operated
Steering brake Brake is oil two direction floating band brake operated by mechanical foot pedal
Final drive The final drive are double reduction with spur gear and segment sprocket, which a sealed by duo-cone seal



Description:



TY165-2 bulldozer is 15 horsepower track-type dozer with hydraulic direct drive, semi-rigid suspended and hydraulic assistinng operating, pilot hydraulic blade control. TY165-2 bulldozer is characterized by high efficient, open view, optimized structure, easy operation and service with low cost and reliable entire quality. It can be equipped with three shanks ripper, U-blade (5.2 cubic meter capacity) and other optional components.

TY165-2 bulldozer is applicable for earth handing in road construction, desert and oil field working, farmland and port construction, irrigation and electric power engineering, mining and other engineer conditions.

It is the upgrade product of TY165 bulldozer.
