Product Details:
Payment & Shipping Terms:
|
Model: | XG6032D | Engine: | Cummins A1700 |
---|---|---|---|
Operating Weight (kg): | 3100 | Rated Power (KW): | 27.8 |
Rated Speed (r/min): | 2800 | Swing Angle (°): | ±12° |
High Light: | road machinery equipment,road construction safety equipment |
Specification:
Model | XG6032D | Steering Angle (°) | ±30° |
Engine Model | Cummins A1700 | Rated Speed (r/min) | 2800 |
Rated Power (KW) | 27.8 |
Overall Dimensions (L×W×H) (mm) |
2780×1370×2576 |
Operating Weight (kg) | 3100 | Swing Angle (°) | ±12° |
Drum(D×W) (mm) | φ700×1200 | Vibration Frequency (Hz) | 50 |
Theoretical Gradeability (%) | 20 | Nominal Amplitude (mm) | 0.5 |
Min. Turning radius (mm) | 4450 | Centrifugal Force (KN) | 30 |
Min. Ground Clearance (mm) | 260 | Speed Range (Km/h) | 0-10 |
Description:
It can also be used for compacting small foundations and sub-foundations, sand soil and gravel materials.
Advantage:
1.The spacious cab provide exceptional visibility.
2.Hydraulic pumps, motors are SAUER or REXROTH products, and vibratory bearings are imported from Sweden SKF or Germany FAG.
3.Hydrostatic drive on both drums. Vibration on front or both drum. Smooth running is realized as a result of continuous speed control.
4.Fork-type frameless body structure ensures superior performance while working on edges.
Application:
It is particularly designed for compacting the ground or asphalt surface of city roads, stadiums, municipal works, etc.
