|Total Weight (Kg):||16200||Blade:||3965×610|
|Number Of Gears:||F6/R3||Drive Type:||Rear-axle Drive|
XG3200C Motor Grader with Dongfeng Cummins engine with rated power 160 kw
|Model Technical Parameter||XG3200C|
|Rated Power (kw/hp)||160 /215|
|Rated Speed (rpm)||2200|
|Height× String Height (mm)||3965×610|
|Reversing Angle (°)||360|
|Max. Blade Angle (°)||90|
|Cutting Depth (mm)||500|
|Drive Type||Motor + worm case|
|Number of Gears||F6/R3|
|Forward Speed (Km/h)||5.1,8.7,11.4, 19.5,24.1,40.1|
|Reverse Speed (Km/h)||5.1,11.4,24.1|
|Drive Type||Rear-axle drive|
|Max. Traction Force (KN)||≤88|
|Articulation Angle (°)||25, right and left|
|Type of Service Brake||Hydraulic disc brake|
|Type of Parking Brake||Hand-operatedshoe-type brake|
|Total Weight (Kg)||16200|
|Basic Overall Dimensions (mm) (L×W×H)||9305×2595×3400|
|Full Overall Dimensions (mm) (L×W×H)||10840×2750×3400|
As China motor grader manufacturer and supplier, we believe that we can offer you high quality with low price Chinese motor grader. Generally motor grader is used to even road base when the road is constructed, sometimes motor graders are used in maintaining dirt roads and gravel roads, even the grassland and snow removal, motor grader is essential equipments in farms, ranches, construction industry, municipal service etc. sometimes, motor grader is called road grader, because of road construction using, it is not all of the use of motor grader.
We have in the business of heavy equipments for many years, nowadays we can provide various kinds of heavy equipments that we are manufacturing such as hydraulic vibrating road roller, crawler excavator, crawler bulldozer, motor grader, wheel loaders. Here we simply introduce the motor grader we make below:
1. The motor grader has been equipped Cummins diesel engine which is turbocharged, inter-cooled, the engine has lower noisy and compact, it make the motor grader is powerful and working quit
2. The motor grader are adopted hydrodynamic torque converter, the gearbox of transmission system is used the gearbox maker of China.
3. The hydraulic system of motor grader has double-pump, dual-circuit for stability and reliability.
4. Breaking system of our motor grader is used the advanced technology to make operating safe, the hydraulic breaking system makes the motor grader easily controlled and operating.
