Product Details:
Payment & Shipping Terms:
|
| Model: | XG5140 | Rated Lifting Capacity: | 14000kg |
|---|---|---|---|
| Load Center Distance: | 600mm | Max. Lifting Height: | 3500mm |
| Minimum Ground Clearance: | 250mm | Engine Rated Power/ Speed: | 125/2200 Kw/r • P • M |
| High Light: | forklift loading truck,forklift lift truck |
||
Warehouses Forklift Pallet Truck Freely Adjusted Seat 20000Kg Dead Weight
Specification:
| Product | XG5140 | Max. Lifting Height(mm) | 3500 |
| Rated Lifting Capacity(kg) | 14000 | Free Lifting Height(mm) | 180 |
| Deadweight(kg) | 20000 | Minimum Ground Clearance(mm) | 250 |
| Fork: L x W x H(mm) | 1800x180x90 | Track (Front/rear)(mm) | 2060/2330 |
| Minimum Turning Radius(mm) | 5800 | Wheelbase(mm) | 3800 |
| Overall Dimensions(LxBxH)(mm) | 7360x2750x3600 | Front tyre | 4-12.00-24/18PR |
| Travel Speed: Forward 1-2/Backward (km/h) | 10-25/12.5 | Rear tyre | 2-12.00-20/16PR |
| Gradeability (%) | 20 | Engine Model | D6114ZG9B |
| Load Center Distance(mm) | 600 | Engine Rated Power/ Speed (kw/r • p • m)) | 125/2200 |
| Tilt Angle of Mast (F/B)( °) | 6° /12° |
Engine Max. Torque Speed (N • m/r • p • m) |
650/1400
|
| Fully-loaded Lifting Speed (mm/s) | 300 | Engine Fuel Consumption Rate (g/kw.h) | 228 |
Description:
Has heavy duty torque converter installed for smooth rotation of power within the internal combustion engine, to rotating-driven loads. Torque converter supersedes the mechanical clutch, effectively allowing the load to be configured from the power source.
Application:
Widely used in short distance transportation as well as loading unloading, and piling goods at warehouses and industrial and mining companies, port, wharf, station, warehouse.
Advantage:
1. Steering axle: adopt full-hydraulic steering gear with transverse cylinder, which helps ensure flexible steering and high reliability
2. The gearbox and torque converter are of reliable quality and stable performance.
3. SINOMTP-140 forklift can be equipped with optional lateral displacement function to facilitate piling during the operation.
4. High strength solid steel Gantry fork.
