Overhead Guard Designed Industrial Forklift Truck Adjustable Safety Seat

China Overhead Guard Designed Industrial Forklift Truck Adjustable Safety Seat supplier

Large Image :  Overhead Guard Designed Industrial Forklift Truck Adjustable Safety Seat

Product Details:

Place of Origin: China
Brand Name: SINOMTP
Certification: ISO/CCC/BV/CE
Model Number: SINOMTP-FB18

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: Negotiation
Packaging Details: Nude, but with wax sprayed.
Delivery Time: 25 working days after received payment
Supply Ability: 500 units per month
Detailed Product Description
Model: SINOMTP-FB18 Power Source: Battery
Rated Load Capacity: 1800kg Load Centre: 500mm
Fork Size (L×W×T): 920x120x35mm Wheelbase: 1380mm

Overhead Guard Designed Industrial Forklift Truck Adjustable Safety Seat





Specification:



Product model SINOMTP-FB18 Overhead Guard Height(mm) 2170
Power source Battery Wheelbase(mm) 1380
Rated load capacity(kg) 1800 Overall length(with forks)(mm) 3070
Load centre(mm) 500 Gradeability(Laden)(%) 15
Lift height(mm) 3000 Front Tire 6.50-10-10PR
Fork size (L×W×T)(mm) 920x120x35 Rear Tire 5.00-8-10PR
Overall Length(Length to fork face)(mm) 2150 Backrest height(from upper fork face)(mm) 800
Overall Width(mm) 1090 Free lift(mm) 115
Mast Lowered Height(mm) 1995 Drive motor(kw) 8/8
Mast Extended Height(mm) 3945 Lift motor(kw) 10/10
Fork carriage tilt(F/R)( °) 6°/12°



Description:



The instruments offer an easy access to the truck, thus makes handling. And powerful engine ensures SINOMTP truck’s high handing performance and offers an intrinsically safety and efficient operation. Process more efficient and safe.



Application:



This kind of forklift used for loading, unloading and stock filing of containers as well as other packages.



Advantage:



1. Side cover can be quickly removed without any tools. Hook cover open angle ≥90°,makes a convenient battery maintenance.

2. Waterproof, dustproof and shockproof LCD instrument.

3. Motor: side-mounted pump motor makes easier maintenance.

4. Brake system: air-over-oil brakes of good reliability with brake master cylinder and brake light.

Overhead Guard Designed Industrial Forklift Truck Adjustable Safety Seat
