Product Details:
Payment & Shipping Terms:
|
| Model: | SINOMTP-FB20 | Power Source: | Battery |
|---|---|---|---|
| Rated Load Capacity: | 2000kg | Load Centre: | 500mm |
| Fork Size (L×W×T): | 1070x120x40mm | Wheelbase: | 1510mm |
| High Light: | forklift pallet truck,forklift lift truck |
||
SINOMTP battery power source forklift rated load capacity 2000kg
Specification:
| Product model | SINOMTP-FB20 | Overhead Guard Height(mm) | 2240 |
| Power source | Battery | Wheelbase(mm) | 1510 |
| Rated load capacity(kg) | 2000 | Overall length(with forks)(mm) | 3430 |
| Load centre(mm) | 500 | Gradeability(Laden)(%) | 15 |
| Lift height(mm) | 3000 | Front Tire | 7.00-12-12PR |
| Fork size (L×W×T)(mm) | 1070x120x40 | Rear Tire | 18x7-8-14PR |
| Overall Length(Length to fork face)(mm) | 2360 | Backrest height(from upper fork face)(mm) | 994 |
| Overall Width(mm) | 1090 | Free lift(mm) | 125 |
| Mast Lowered Height(mm) | 1160 | Drive motor(kw) | 11.1/8 |
| Mast Extended Height(mm) | 4020 | Lift motor(kw) | 12/15 |
| Fork carriage tilt(F/R)( °) | 6°/12° | ||
Description:
Specially designed solid overhead guard provides additional security for the operator.
Application:
This kind of forklift used for loading, unloading and stock filing of containers as well as other packages.
Advantage:
1. Reliable Quality: Carefully select regular manufacturers for supporting spare parts, like engines, bridge, transmissions, and many parts designed and produced by ourselves, always adapting the best materials.
2. Supper low and non-slip make operating convenient and safe.
3. The instruments offer an easy access to the truck, thus makes handling process more efficient and safe.
4. Spacious workplace: Ample leg room helps to provide a relaxed, working environment, keeping the operator relaxed and focused throughout the working day for maximum productivity.
