Product Details:
Payment & Shipping Terms:
|
| Model: | SINOMTP-FB30 | Power Source: | Battery |
|---|---|---|---|
| Rated Load Capacity: | 3000kg | Free Lift: | 130mm |
| Lift Height: | 3000mm | Drive Motor: | 16.6/9kw |
| High Light: | forklift pallet truck,forklift lift truck |
||
130mm Free Lift Electric Battery Powered Lift Truck SINOMTP High Strength Integral Hood
Specification:
| Product model | SINOMTP-FB30 | Overhead Guard Height(mm) | 2250 |
| Power source | Battery | Wheelbase(mm) | 1700 |
| Rated load capacity(kg) | 3000 | Overall length(with forks)(mm) | 3630 |
| Load centre(mm) | 500 | Gradeability(Laden)(%) | 15 |
| Lift height(mm) | 3000 | Front Tire | 28x9-15-12PR |
| Fork size (L×W×T)(mm) | 1070x125x45 | Rear Tire | 18x7-8-14PR |
| Overall Length(Length to fork face)(mm) | 2560 | Backrest height(from upper fork face)(mm) | 930 |
| Overall Width(mm) | 1230 | Free lift (mm) | 130 |
| Mast Lowered Height(mm) | 2120 | Drive motor(kw) | 16.6/9 |
| Mast Extended Height(mm) | 4160 | Lift motor(kw) | 13.5/22 |
| Fork carriage tilt(F/R)( °) | 6°/12° | ||
Description:
High strength integral hood with thermal and sound insulation material, tile-cylinder built-in designs and large operation space greatly improves the operator’s maximum comfort.
Application:
Currently our forklift truck is widely used in logistics operation sites like port, wharf, industrial and mining enterprises, station and warehouse, construction site, log yard and much more.
Advantage:
1. Spacious workplace: Ample leg room helps to provide a relaxed, working environment, keeping the operator relaxed and focused throughout the working day for maximum productivity.
2. Humanized right-side hydraulic operation handle and emergency power-off button.
3. The controller is directly fixed in the balanced weight to lead better heat dissipation
4. It has good performance by sealing fuel tank structure and multi-function valve with forward self-locking.
