4 Cylinder Industrial Forklift Truck Sinomtp FD10 1000kg Diesel ISUZU engine

China 4 Cylinder Industrial Forklift Truck Sinomtp FD10 1000kg Diesel ISUZU engine supplier

Large Image :  4 Cylinder Industrial Forklift Truck Sinomtp FD10 1000kg Diesel ISUZU engine

Product Details:

Place of Origin: China
Brand Name: SINOMTP
Certification: ISO/CCC/BV/CE
Model Number: SINOMTP-FD10

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: Negotiation
Packaging Details: Nude, but with wax sprayed.
Delivery Time: 25 working days after received payment
Supply Ability: 500 units per month
Detailed Product Description
Model: SINOMTP-FD10 Power Source: Diesel
Rated Load Capacity: 1000kg Load Centre: 500mm
Fork Size (L×W×T): 920×120×35 Mm No. Of Cylinder: 4

4 Cylinder Industrial Forklift Truck Sinomtp FD10 1000kg Diesel ISUZU engine





Specification:



Item FD10
Power source Diesel
Rated load capacity 1000 kg
Load centre 500 mm
Lift height 3000 mm
Fork size (L×W×T) 920×120×35 mm
Fork carriage tilt(F/R) 6°/12°
Overal Length(Length to fork face) 2205 mm
Overall Width 1086 mm
Mast Extended Height 3940 mm
Mast Lowered Height 1995 mm
Overhead Guard Height 2040 mm
Gradeability(Laden) 20 %
Front Tire 6.50-10-10PR
Rear Tire 5.00-8-10PR




Description:



Engine Brand ISUZU
Model C240PKJ
Rated output 35.4/2500kw/r.p.m
Rated torque 139/1800Nm/r.p.m
No. of cylinder 4
Bore x Stroke 86X102mm
Displacement 2369cc



Advantage:



1. Specially designed solid overhead guard provides additional security for the operator.

2. Wide-view mast gives the operator an enhanced forward visibility, which adds to the efficiency and safety of operator.

3. The instruments offer an easy accesses to the working condition of the truck, thus makes handling process more efficient and safe.

4. Supper low and non-slip make operating convenient and safe.

4 Cylinder Industrial Forklift Truck Sinomtp FD10 1000kg Diesel ISUZU engine4 Cylinder Industrial Forklift Truck Sinomtp FD10 1000kg Diesel ISUZU engine
