|Operating Weight (Ripper Not Included):||37.2t||Blade Type:||Straight Tilt|
|Blade Width:||Straight Tilt Blade 4130×1590 Mm||Dozing Capacity:||Straight Tilt Blade 10 M3|
shantui construction machinery,
dozer construction equipment
Straight Tilt Blade Crawler Bulldozer 1560mm Lift Height With Cummins Engine
|L×W×H (Ripper not included)||6880×4130×3725 mm||Ripping depth of ripper||
Single ripper 1250mm
Three-shank ripper 842 mm
|Operating weight (Ripper not included)||37.2t|
|Rated power||235/2000kW/rpm||Lifting height of ripper||Single ripper 955Three-shank ripper 883|
|Gradeability||30°||Number of carriers (each side)||2|
|Blade type||Straight tilt||Number of track rollers (each side)||7|
Straight tilt blade 4130×1590 mm
|Number of track shoes (each side)||41|
|Width of track shoe||560 mm|
|Track gauge||2140 mm|
|Ground length and ground pressure||3150-0.105 mm/MPa|
|Dozing capacity||Straight tilt blade 10 m3||Pitch||228.6mm|
|Ma× drop below ground of blade||560 mm||Reverse speed||0–4.4km/h|
|Lift height of blade||1560 mm||0–7.8km/h|
|Ripper type||Single ripperThree-shank ripper||0–13.5km/h|
Based on the Shantui TY320B, the SD32 bulldozer was developed by Shantui for operation in earth moving projects with tough conditions. Equipped with a hydraulic drive system with hydraulic control technology and an advanced structure, which provides reliable performance and convenient and flexible operation, the SD32 is the ideal medium size construction machine for earth moving projects.
1. The full box-type main frame with application of high performance materials and high strength castings features high carrying capacity against impact load and bending moment to support the continuous high-strength working of machine under severe working condition and the high quality welds guarantee the life cycle of the main frame.
2. The low-drive final drive can provide powerful drive force and efficient grade ability. Shantui's crawler chassis has reached the international advanced level in process level and can adapt to various complicated working conditions, featuring high reliability and carrying capacity.
3. The standard straight tilting blade features powerful cutting force and the single-shank and three-shank rippers of adjustable penetrating angle can be used for the ripping of clay and frozen earth as well as the stripping of hard working faces, such as gravel and hardened salt mine.
