Product Details:
Payment & Shipping Terms:
|
| Operating Weight: | 17900kg | Engine: | Shanghai C6121ZG58 |
|---|---|---|---|
| Engine Power: | 180hp | Blade Type: | Angle Blade |
| Blade Width * Height: | 3970x1050mm | Blade Capacity: | 4.3 M3 |
| Track Gauge: | 1880mm | Track Type: | Sealed, Assembled Single-grouser |
| High Light: | shantui construction machinery,dozer construction equipment |
||
XGMA XG4180F bulldozer with Straight-tilt blade , optional"U" type and Angle blade
Specification:
| Model | XG4180F | Engine model |
Shangchai C6121ZG58 |
| Blade type | Angle blade | Blade capacity | 4.3m³ |
| Track gauge | 1880 mm | Track type | Sealed, assembled single-grouser |
| Operating weight | 18200kg | Main ground Clearance | 400 mm |
| Min turning radius | 3.3m | Grade ability | 30° |
| Blade width * height | 3970x1050mm | Max Depth | 545 mm |
| Max lifting | 1250mm | Working cylinder type | Double-acting piston type |
| Width of Track shoes | 510mm |
Flywheel horse power |
180hp |
| Engine oil capacity | 45L | Hydraulic tank capacity | 108L |
Description:
Industry-leading driving force, efficient work, Sensitive and reliable manipulation, easy to maintain.
Advantages:
1. Awarded the ISO9001:2000 system certificate
2. Engine model: CUMMINS NT855-C280S10 / SHANG CHAI C6121ZG58 / WEICHAI WD10G200E15
3. Flywheel horsepower: 180 HP (135 KW)/1850RPM
4. Operating weight (straight-tilt dozer): 17900KG
5. Made using KOMATSU D60E-8 bulldozer technology, XGMA bulldozer features high performance, great efficiency, safe and reliable operation
6. The bulldozer is suitable to be used in any forestry logging applications
7. Canopy structure ensures excellent visibility and operator safety
8. Optional attachments: straight-tilt blade, angle blade, winch, 3-shank ripper, 510mm track shoes, 610mm track shoes.
Application:
Earth moving projects, bulldozing, digging, landfill, and other bulk operations.
